Designed for Automotive, Battery Management Systems, Industrial Automation, Robotics and Material Handling Equipment. Supports Classical CAN and CAN FD with high-speed USB communication.
Independent CAN FD Channels supporting Classical CAN and CAN FD.
USB 2.0 High Speed interface for low latency communication.
C, C++, C#, Python API for custom applications.
Simple firmware update utility included with software.
High resolution timestamps for accurate logging.
Monitor, Logger, DBC Support, Bus Statistics.
| USB Interface | USB 2.0 High Speed |
| CAN Channels | 2 |
| CAN Standard | CAN 2.0A/B + CAN FD ISO |
| Maximum Data Rate | Up to 8 Mbps |
| Driver | Windows 10 / 11 |
| SDK | C, C++, C#, Python |
| Firmware Upgrade | Supported |
| Power | USB Powered |
